Specifications



Stent material

L605 Cobalt Chromium Alloy

Strut Thickness

60 micron

Drug

Sirolimus 1.0 µg/mm2

Crossing Profile

0.095 mm (0.037”)

Recoil

≤ 2 %

MRI Compatibility

MR conditional

Compliance

Nominal: 8 atm, RBP: 14 atm /16 atm

Diameter

2.25, 2.50, 2.75, 3.00, 3.50, & 4.00 mm

Length

7, 10, 13, 15, 17, 20, 24, 28, 33, 38, 42, 45 & 48 mm

YOUR NEED OUR INNOVATION

DOWNLOAD e-BROCHURE

We strive to provide you with the detailed information of your desired choice of product.

The product story folded in the brochure to unfold the same download e-Brochure and know more about the key features, benefits, technical specifications and others.

Inquiry Now Download e-Brochure

Stent Features

  • * crowns for uniform & optimum vessel scaffolding
  • Customized crown length for 2.25, 2.50, 2.75, 3.0, 3.5, & 4.0 mm
  • Maintain consistent metal-artery ratio
  • Innovative “S” link and alternate "C" link design
  • Superior stent strength through strong cobalt chromium alloy
  • Thin Strut (60 µm)
  • Drug : Sirolimus 1.0 µg/mm2
  • Thin drug/polymer coating thickness: 4-5 micron
  • Excellent deliverability & conformability
  • Growth of 8 % from nominal pressure to RBP allowing complete deployment and good wall apposition
  • Available in length up to 48 mm

Highlights

  • Minimal Balloon Overhang which minimizes risk of edge dissection
  • High radial strength which makes it ideal for proximal lesion
  • Low recoil ensures predictable results
  • Low deflation time
  • Excellent & uniform scaffolding
  • No Foreshortening suitable for Ostial lesion

Technical Data

Catalog No.

Length/Dia 2.25mm 2.50mm 2.75mm 3.00mm 3.50mm 4.00mm
07mm NH 0722 NH 0725 NH 0727 NH 0730 NH 0735 NH 0740
10mm NH 1022 NH 1025 NH 1027 NH 1030 NH 1035 NH 1040
13mm NH 1322 NH 1325 NH 1327 NH 1330 NH 1335 NH 1340
15mm NH 1522 NH 1525 NH 1527 NH 1530 NH 1535 NH 1540
17mm NH 1722 NH 1725 NH 1727 NH 1730 NH 1735 NH 1740
20mm NH 2022 NH 2025 NH 2027 NH 2030 NH 2035 NH 2040
24mm NH 2422 NH 2425 NH 2427 NH 2430 NH 2435 NH 2440
28mm NH 2822 NH 2825 NH 2827 NH 2830 NH 2835 NH 2840
33mm NH 3322 NH 3325 NH 3327 NH 3330 NH 3335 NH 3340
38mm NH 3822 NH 3825 NH 3827 NH 3830 NH 3835 NH 3840
42mm NH 4222 NH 4225 NH 4227 NH 4230 NH 4235 NH 4240
45mm NH 4522 NH 4525 NH 4527 NH 4530 NH 4535 NH 4540
48mm NH 4822 NH 4825 NH 4827 NH 4830 NH 4835 NH 4840

Compliance Chart

Pressure (bar) 2.25mm 2.50mm 2.75mm 3.00mm 3.50mm 4.00mm
4 1.98 2.25 2.48 2.74 3.25 3.72
6 2.13 2.39 2.62 2.88 3.35 3.85
8 2.25 2.50 2.75 3.00 3.50 4.00
9 2.28 2.54 2.78 3.03 3.54 4.07
10 2.31 2.57 2.82 3.10 3.57 4.14
11 2.33 2.60 2.86 3.13 3.60 4.19
12 2.35 2.62 2.89 3.17 3.63 4.25
13 2.37 2.64 2.91 3.19 3.66 4.28
14 2.39 2.66 2.93 3.21 3.70 4.32
15 2.41 2.68 2.95 3.23 3.74 4.35
16 2.43 2.70 2.97 3.25 3.78 4.38
17 2.45 2.73 3.00 3.28 3.81 4.40
18 2.48 2.76 3.03 3.31 3.84 4.42
  Nominal Pressure   Rated Burst Pressure
