Specifications



Nominal Pressure

14 ATM

Rated Burst Pressure

20 ATM

Average Inflation / Deflation Time

7 Secs

Distal Shaft Diameter

2.7 F

Lumen inner Diameter

0.015"

Tip Entry Profile

0.017"

Tip Length

3 ± 1 mm

Distal Shaft

Hydrophilic Coated

Proximal Shaft Diameter

2.3 F

Marker Band

Platinum / iridium

Hypo tube

Over jacketed

Balloon Crossing Profile
0.82 mm, 0.92 mm, 1.02 mm

Excellent Stent apposition with controlled balloon expansion

Less than 5 % growth at RBP (20 ATM)

2 % growth at 16 ATM

Double marker allows precision placement

Technical Data

Catalog No.

Length/Dia 2.00mm 2.25mm 2.50mm 2.75mm 3.00mm 3.50mm 4.00mm
10mm VN 1020 VN 1022 VN 1025 VN 1027 VN 1030 VN 1035 VN 1040
15mm VN 1520 VN 1522 VN 1525 VN 1527 VN 1530 VN 1535 VN 1540
20mm VN 2020 VN 2022 VN 2025 VN 2027 VN 2030 VN 2035 VN 2040
25mm VN 2520 VN 2522 VN 2525 VN 2527 VN 2530 VN 2535 VN 2540
30mm VN 3020 VN 3022 VN 3025 VN 3027 VN 3030 VN 3035 VN 3040

Compliance Chart

 Diameter (mm)
Pressure (bar)2.533.5
42.242.713.03
62.292.793.12
82.362.853.24
92.392.873.28
102.422.913.32
112.442.933.35
122.462.963.39
132.482.983.43
142.503.003.47
152.523.023.50
162.543.053.52
172.563.063.55
182.573.083.57
192.593.103.60
202.603.123.62
212.623.143.65
222.633.153.68
232.643.193.71
242.663.223.74
  Nominal Pressure   Rated Burst Pressure
